Micro spike spot

Available finishes:

RAL Number (if CUSTOM RAL):

Available LED:

Available optics:

Available cable length:

Available options: Glare guard (Micro)+£25.00100mm longer rod+£15.00200mm longer rod+£20.00250mm longer rod+£25.00300mm longer rod+£29.00800mm Rod out of ground (2 x 300mm sections, 1 x 200mm section and 1 x 200mm ground rod)+£99.00Pre aging of Brass, Copper or Bronze+£20.00Upgrade CRI to 95+£10.00

Your Order Summary

Config:—

Cable:—

Accessories:None

Total Price Loading... incl. VAT

Create an account to add to basket

10-Year
Guarantee

Free Trade
Support

Production Timeline: Estimated dispatch from Thursday, 20th August 2026

View our current production timeline | We can often accommodate urgent orders - contact us

Enhance your outdoor lighting design with the compact and versatile Micro Spike Spot. Perfect for highlighting smaller features and creating intimate focal points, this lighting solution is ideal for illuminating plants, sculptures, or architectural details. Its sleek and unobtrusive design ensures it blends seamlessly into your outdoor space, adding a subtle yet impactful touch to your landscape.

Key Features and Benefits:

Submersible and waterproof (IP68 rated)
Small but powerful, with a user-replaceable LED
10-year guarantee for peace of mind
Pre-flexed with 2 meters of 2-core flex (optional longer leads available)
Dimmable for customizable lighting effects
Reverse polarity-proof design with a diode bridge for simplified installation
All components are replaceable, ensuring the fitting’s longevity far beyond the warranty

Specifications:

Must be used with 350mA LED drivers, wired in series only
42W Max (120VDC)

The Micro Spike Spot combines precision and durability to deliver exceptional lighting performance, making it the perfect choice for enhancing your outdoor environment.

Submersible (IP68) Small, but powerful with a user-replaceable LED. 10-year guarantee. Pre-flexed with 2 meters of 2 core flex. Dimmable. Reverse polarity protection illuminates Red when connected in reverse. All components of the fitting are replaceable allowing for the longevity of the fitting beyond the warranty for years to come. Must be used with 350mA LED drivers, wired in series only. 42W Max (120VDC)

Specification Sheet

Image Pack

SketchUp Model

IES File — 3.6W

IES File — 2.6W

IES File — 1.6W

TM66 Circular Economy Assessment

Category	Points Scored	Max Points	Assessment
Product Design	97.0	134.0	2.9
Manufacturing	27.0	46.5	2.3
Materials	10.0	24.0	1.7
Ecosystem	36.0	43.0	3.3
Overall	170.0	247.5	2.6

Score Range Key
0 to 0.5	Very poor circular economy performance
0.5 to 1.5	Some circular economy functionality
1.5 to 2.5	Definite/substantial progress to circularity
2.5 to 4.0	Excellent circularity

Watch the product & installation video

Lighting effect — 1.6W VS 2.6W VS 3.6W VS 6W VS 12W

Customer Photos

Professional Resources

Technical documentation for architects and specifiers.

Spec Sheet 3D / SketchUp Image Pack Photometrics

Download Full Pack
